GT30 Stainless Steel Housing - TiAL Sport

002459

£495.97

Lightweight stainless steel turbine housings for the GT/X 30 series turbochargers. Compatible with the 60mm 84 trim turbine wheel. Note: these housings will not work with the 700177-23 GT3071R CHRA, the heat shield is different, you must use the 700177-22 CHRA.

Specifications

Typically lighter weight than a corresponding iron housing of the same A/R
Investment cast stainless steel for a beautiful, smooth interior and exterior
Vband inlet and outlet gets rid of gaskets and bolts, no leaks and no broken bolts
Three A/R options
Overall physical size is smaller than standard housing, allowing it to fit in tight engine bays
Better heat retention than cast iron
Inconel bolts provided for vibration and stretching resistance in extreme applications
Locking tabs included for high vibration applications
Pivoting of the turbo 360* possible
Note: these housings will not work with the 700177-23 GT3071R CHRA, the heat shield is different, you must use the 700177-22 CHRA

Included with every housing:

Turbine Housing
Three Moon Tabs
Six Inconel Bolts
Three Locking Tabs

TiAL V-Band Clamp & Flange System:

TiAL V-Band flanges are manufactured in house
GTVFL3.0 - Inlet Flange
VC300 - Inlet Clamp
VBF300M - Outlet Flange
VC355 - Outlet Clamp

CONFIGURATION

GT30 Housing	Option
Flange Materials	304L Stainless
Pipe Size	Inlet Flange: 2.125" OD, Outlet Flange: 3.00" OD
Flanges/Clamps Included?	No
Housing Weight	5.8lbs (largest A/R)
Turbine Wheel	60mm 84 Trim
